Weefine WED-5 PRO 5" Professional Monitor
1’199.00
CHF
/ Pc.
incl. 8.1% Tax
Stock:
0
Art. no.: WED-5 PRO
Remember
Description
Weefine Monitor
Weefine WED-5 PRO – 5" FHD, 3200 nit, 4K/60 HDMI, 100 m
Rugged aluminum underwater monitor – lightweight, travel-friendly and durable. With 3200 nit brightness, 4K/60 HDMI, 3D LUT import and USB firmware updates, perfect for precise V-Log workflows and professional underwater video production.
Highlights
- 5" Full HD (1920×1080), 443 ppi, Rec.709 color accuracy
- Ultra-bright: 3200 nit with auto backlight – excellent readability in sunlight
- 4K/60 HDMI input & HDMI output; includes M24/M16 adapter & HDMI cables (A/C/D)
- Pro tools: Waveform, Vectorscope, RGB Parade, False Color, Zebra, Peaking
- 3D LUT import & USB updates – optimized for V-Log workflows
- No touchscreen – optimized buttons & dial for underwater use
- Depth rating 100 m – hard-anodized aluminum housing
- Lightweight & compact: approx. 720 g on land, ~250 g underwater
Note: For reliable HDMI signal transmission, use short, high-quality cables and ensure stress-free routing (M24/M16).
5" FHD
3200 nit
4K/60 HDMI
100 m
3D LUT
Specifications
| Display | 5" LCD, 1920×1080, 443 ppi, Rec.709 |
|---|---|
| Brightness | 3200 nit (max), auto backlight |
| Video I/O | HDMI 2.0; input 4K/60 fps; HDMI output |
| Functions | Waveform, Vectorscope, RGB Parade, Histogram, False Color, Zebra, Peaking, 3D LUT |
| Controls | Dial & buttons (no touchscreen) |
| Battery | WBL-12C / 21700 Li-Ion, 3.6 V 5000 mAh; approx. 90 min runtime |
| Depth rating | 100 m |
| Dimensions | 183.5 × 104 × 51.5 mm |
| Weight | 720 g (land), ~250 g (underwater) |
| Temperature | Operating 0–40 °C / Storage -20–60 °C |
In the Box
- WED-5 PRO Monitor
- External HDMI cable & USB-C charging cable
- M24/M16 bulkhead adapter, HDMI cables Type A/C/D
- Sun hood, ball joint adapter (top/bottom)
- WBL-12C battery, O-rings, silicone grease, cleaning cloth, tools
- Documentation & warranty card
FAQ
Does the monitor have a touchscreen?
No. Operation is via dial and waterproof buttons – optimized for underwater use.
Can I load my own 3D LUTs?
Yes. 3D LUTs can be imported via USB – perfect for precise color grading (e.g. V-Log).
How long does the battery last?
Approx. 90 minutes per 21700 battery (WBL-12C), depending on brightness and usage.
What is the maximum depth rating?
Rated to 100 m (manufacturer specification).
Advice & Availability
We are happy to put together a complete kit with cables, mounts, arms and a carrying case – customized for your housing and setup.
